* Information for using 18V Li-ion battery with 5.0Ah.
| Model / Type | EY46A2LJ2G | EY46A2X |
|---|---|---|
| Voltage | 18V | 18V / 14.4V |
| Battery capacity accord. to IEC (Technology) | 5.0Ah (Li-ion) | * |
| Charging time (usable / full) | 65 / 80min. | * |
| Speed at no load in rpm | 10.000 | * |
| Disc size (outer Diameter) | 125mm | * |
| Size (W x L x B) | 105 x 345 x 141mm | * |
| Weight (incl. battery) | 2.35kg | * |
| Standard accessories (battery / charger / plastic box) | 2 x battery EY9L54B Charger EY0L82B incl. plastic box |
without without without |
* X-type (EY46A2X) without battery and charger.
| Battery capacities | ||
|---|---|---|
| Voltage | 18V | |
| Model | EY46A2LJ2G | |
| Battery | EY9L54B(LJ) | |
| Reinforcing bar | Ø 10 mm | 140pcs/charge |
| W3/8 Continuous thread stud (Mild steel) | 180pcs/charge | |
150 %* DYNAMIC POWER WITH 18 V
With all new, larger 18 V motor, the EY46A2 offers more than 150 %* higher power, speed and workload. It enables continuous operation even under substantial load.
This combined with our high performance 4.2 Ah capacity Li-ion battery will suit heavy demands even on tough applications.
*compared with current model EY4640 (14.4 V)
Even with increased performance, the EY46A2 is more compact and approx. 25 mm shorter than current EY4640 model. This makes it ideal for use in restricted work areas such as under a roof or floor whilst still offering a wider range of applications due to larger 125 mm disc capacity.
Thanks to ‘On-lock start prevention’ function, the grinder will not start when a battery pack is inserted with the switch at the ON position. (The warning lamp will flash at this time.) Additionally ‘Battery overheat protection’ cuts off power to the motor before the battery temperature rises to a harmful level and flashes a warning lamp on the tool’s control panel to notify the user.
Delivery Info
* Information for using 18V Li-ion battery with 5.0Ah.
| Model / Type | EY46A2LJ2G | EY46A2X |
|---|---|---|
| Voltage | 18V | 18V / 14.4V |
| Battery capacity accord. to IEC (Technology) | 5.0Ah (Li-ion) | * |
| Charging time (usable / full) | 65 / 80min. | * |
| Speed at no load in rpm | 10.000 | * |
| Disc size (outer Diameter) | 125mm | * |
| Size (W x L x B) | 105 x 345 x 141mm | * |
| Weight (incl. battery) | 2.35kg | * |
| Standard accessories (battery / charger / plastic box) | 2 x battery EY9L54B Charger EY0L82B incl. plastic box |
without without without |
* X-type (EY46A2X) without battery and charger.
| Battery capacities | ||
|---|---|---|
| Voltage | 18V | |
| Model | EY46A2LJ2G | |
| Battery | EY9L54B(LJ) | |
| Reinforcing bar | Ø 10 mm | 140pcs/charge |
| W3/8 Continuous thread stud (Mild steel) | 180pcs/charge | |
150 %* DYNAMIC POWER WITH 18 V
With all new, larger 18 V motor, the EY46A2 offers more than 150 %* higher power, speed and workload. It enables continuous operation even under substantial load.
This combined with our high performance 4.2 Ah capacity Li-ion battery will suit heavy demands even on tough applications.
*compared with current model EY4640 (14.4 V)
Even with increased performance, the EY46A2 is more compact and approx. 25 mm shorter than current EY4640 model. This makes it ideal for use in restricted work areas such as under a roof or floor whilst still offering a wider range of applications due to larger 125 mm disc capacity.
Thanks to ‘On-lock start prevention’ function, the grinder will not start when a battery pack is inserted with the switch at the ON position. (The warning lamp will flash at this time.) Additionally ‘Battery overheat protection’ cuts off power to the motor before the battery temperature rises to a harmful level and flashes a warning lamp on the tool’s control panel to notify the user.
